News:
1/2-05-2010 IARU 2nd Subregional test
It was amazing contest.
I was QRV on 144MHz in JO82KL 135m ASL + 9m AGL, with Icom ic-275A (ONLY 25W!) and my new antenna (many thanks for Justin) 9el OWL G0KSC 12dBD. QSO:157; Points: 65207 ODX: HB9GT 803km AVG QRB: 415km
I heard many DX stations.
Great conditions to DL, poor to 9A, first time log without 9A... big signals from HA stations, not so many OK stations in log.
I made lot of audio records, soon will be published. Gallery
READ MORE...
04-2010 Preparing to KP4AO EME activity
I will try to complete qso with this amazing station between 16-18.04.2010
My equipment 2x 16el Yagi DK7ZB (18.5dBd), PA on GI7B, Transverter MMT432/144, Icom IC-275A.
details of activity
10-03-2010 Great Antenna designe from Justin G0KSC
Justin G0KSC calculate for me amazing antenna for 144.1MHz.
It is 9 elements Yagi (OWL) with 12,5Ohm impedance on 4,9 meter long boom.
It has 12,1dBd of gain, 29dB F/B ratio, 228K temperature, horizontal & vertical -3dB angle 40deg
Page with Details of construction two antennas for EME,MS,Tropo
24-02-2010 SR3PO Repeater
SR3PO JO82LJ 80m ASL + 45m AGL
After failure of our old local repeater we decided to update hardware.
Configuration:
TX: motorola mcs2000; 10W out, 10m H-1000 (439,2MHz CTCSS 210,7Hz)
RX: motorola gm1200; 10m H-1000 (431,6MHz CTCSS 210,7Hz)
Antenna EP X-300 (9dBi 5x5/8)
And our old Siemens duplexer. I tunned it on spectrum analyzer.
New repeater controller made by Krzysztof SQ3FYK (schema)
Coverage simulation
24-02-2010 I'm visible on APRS via GSM.
I'm using Nokia E52 with integred GPS and miGPS software made by SP3FHI. www with software
MY APRS MAP
20-02-2010 New beacons in this year.
In this year we will activate three new beacons (23cm & 6cm & 3cm).
Beacons will be mounted in JO82KL about 90m agl in the same location as SR3VHX at 100m AGL + 105m ASL.
SR3LHD 1296,971MHz pwr 1W & ant Helix 6dB (tnx to DJ6EP & SP3WYP)
SR3CHL 5760,860MHz pwr 1W & ant slot (tnx to OK1AIY & SP6GWN)
SR3XH? 10368,9??MHz pwr 1W (tnx to DL6NCI)
14-11-2009 New beacon SR3LHD QRV !.
SR3LHD JO82LJ 1296,97MHz 1W
Today we mount new beacon made by Roman DJ6EP & Michał SP3WYP.
It is mounted on roof of 10th floor building in Poznan City, about 45m AGL + 75m ASL.
It has power about 1W and antenna is Helix about 6dB? (omni horizontal).
In future, after tests, we are planning add amplifier 5-10W and move it to better location (sr3vhx).
Coverage image(cold be worst to West=high city buildings)
5/6-09-2009 IARU VHF test '09!.
SO3Z JO82KL 118 QSO | 48774 points | avg 413km/qso | 42 squares | 13 DXCC
QRV 144MHz with Ic-275A, 25W, 2x 10el DK7ZB @ 9m AGL + 140m ASL
I worked without 230V, only from 12V accumulator. Also PC&internet only for about 3 hours. I had big rain in saturday, strong wind also all the time.
Tropo conditions were unstable. Very poor to West. Good and variable to South from JO82.
I heard 9A1W, 9A1B, 9A2LX, S52XA, S58M, S53A, PI9A, DR5A, HG7F, HA2R, HG1W, HG3A, OE8GVK/3, OE5MKO, UW5Y,
and two Italy stations, and few OK&DL stations also. TXT info QSO MAP PHOTOS SEND LOGS
4/5-07-2009 3rd IARU test '09!.
SO3Z JO82KL 139 QSO | 53381 points | avg 384km/qso | 51 squares | 15 DXCC
QRV 144MHz with Ic-275A, 150W, 2x 10el DK7ZB @ 8m AGL 140m ASL
TXT info QSO MAP PHOTOS SEND LOGS
14-05-2009 My new contest callsign SO3Z - 'sierra oscar three zulu'
Today I send the papers for my new contest callsign, now waiting for reply.
2/3-05-2009 2nd IARU test '09!.
141 QSO | 59230 points | avg 420km/qso | 50 squares | 12 DXCC
I worked only on 144MHz as usual from JO82KL at my contest hill 140m ASL.
First time with power amplifier 150W and with 3x 7el DK7ZB Yagi vertical stacked.
This antenna is great solution, low elevation angle, stable tropo signals... Realy loud this time PI4GN 9A4M DK0BN and all HA stations.
I hope I will try also 4x 7el Lightweight yagi next time.
I have been visited by Tomasz SQ3LVD, He helped me erect the antenna system - Many thanks Tom!
Before erect the mast I made a mistake, and I couldn't turn my antenna dir north... also in first day I had only two 12V accumulator, need 3.
And first day had only 50W, at 3.05 I had full power 150W. First time worked YO from KN06 station on tropo.
I must check my handwritten log again.
I hope it will be enough for place in first fifth in Single Operator in SP.
TXT info QSO MAP PHOTOS SEND LOGS
I worked only on 144MHz as usual from JO82KL at my contest hill 140m ASL.
First time with power amplifier 150W and with 3x 7el DK7ZB Yagi vertical stacked.
This antenna is great solution, low elevation angle, stable tropo signals... Realy loud this time PI4GN 9A4M DK0BN and all HA stations.
I hope I will try also 4x 7el Lightweight yagi next time.
I have been visited by Tomasz SQ3LVD, He helped me erect the antenna system - Many thanks Tom!
Before erect the mast I made a mistake, and I couldn't turn my antenna dir north... also in first day I had only two 12V accumulator, need 3.
And first day had only 50W, at 3.05 I had full power 150W. First time worked YO from KN06 station on tropo.
I must check my handwritten log again.
I hope it will be enough for place in first fifth in Single Operator in SP.
TXT info QSO MAP PHOTOS SEND LOGS
01-05-2009 QRT :(.
Q R T from home :( :( :(
07/08-03-2009 1st IARU test '09!.
First time on 70cm on IC-275A with transverter MMT432/144 10W out , And 16 elements Yagi DK7ZB at my contest place (140m ASL) 4m AGL.
7.03 - QRV 14-22UTC Realy bad conditions and weather (wind, rain, and cold), only 8 complete QSO.
ODX DL0GTH/p 440km (heard DR5A 760km). Very poor conditions, big qsb, unstable signals.
8.03 - QRV 8-14UTC Better weather, better conditions, but still big qsb. ODX S51ZO 641km. Only 14 QSO Complete in the contest
Worked only DL, OK, SM, SP, S5. I heard also OE and OM.
I heard also stations from JO30, JO32, JO40, JO43, JO52, JO60, JO61, JO72, JO80, JO90, JO93, JN58, JN57, JN77, JN79, JN99. I have been visited by Adam SQ3ET.
7.03 - QRV 14-22UTC Realy bad conditions and weather (wind, rain, and cold), only 8 complete QSO.
ODX DL0GTH/p 440km (heard DR5A 760km). Very poor conditions, big qsb, unstable signals.
8.03 - QRV 8-14UTC Better weather, better conditions, but still big qsb. ODX S51ZO 641km. Only 14 QSO Complete in the contest
Worked only DL, OK, SM, SP, S5. I heard also OE and OM.
I heard also stations from JO30, JO32, JO40, JO43, JO52, JO60, JO61, JO72, JO80, JO90, JO93, JN58, JN57, JN77, JN79, JN99. I have been visited by Adam SQ3ET.
10-02-2009 My second EME QSO!.
I made my second eme qso with RA6AX. He has 64 x 15el Yagi and 1.5kW -20dB was best ;
6-01-2009 My first EME QSO!.
I made my first eme qso with Gary KB8RQ.
Gary has 24 x 13el Yagi with horizontal polarisation, and QRO .
My equipment was Icom IC-275A, Mirage 80W PA,
20meters of H-1000, 10el DK7ZB Yagi (13dBd)
KB8RQ EM79 7287km -20dB was best
Gary has 24 x 13el Yagi with horizontal polarisation, and QRO .
My equipment was Icom IC-275A, Mirage 80W PA,
20meters of H-1000, 10el DK7ZB Yagi (13dBd)
KB8RQ EM79 7287km -20dB was best
4-01-2009 My first EME rx.
I received first time some signals from Moon :) My equipment was Icom IC-275A, 25 meters of H-1000, 10el DK7ZB Yagi (13dBd)
RK3FG from KO86 -22dB signal W7GJ from DN27 -21dB QRZ W7GJ from DN27 -22dB CQ
RK3FG from KO86 -22dB signal W7GJ from DN27 -21dB QRZ W7GJ from DN27 -22dB CQ
